Pocket frame Paralelo Wood Plus

Pocket frame Paralelo Wood Plus

  • Reference: 10.13

Pocket frame for sliding door

Share:



The PARALELO WOOD PLUS is an exclusive solution that enables the use of two overlapping wooden sliding doors of large dimensions. With a double rail embedded on the ceiling, the PARALELO WOOD PLUS pocket frame allows you to separate large areas in a practical and effective way, keeping the space harmony and giving it different features.





FEATURES:

Door type: Wood
Max. door weight: 120 kg


Kit includes:
- 1 Pocket frame;
- 1 Aluminium track;
- 1 Wood doorpost;
- 2 Pocket frame accessories Kits 10004;
- 1 Floor guide for parallel doors 7007 + 7013;
- 2 Metallic spacer;
- 4 Glass fiber mesh (for mortar wall);
- 3,5x19 mm screws (for the plasterboard version).



Available options:
EASY SOFT brake damper





Technical sheet Technical sheet Download
Informative and Commercial Document Informative and Commercial Document Download
Warranty Conditions Warranty Conditions Download
Assembly instructions – Large dimensions Assembly instructions – Large dimensions Download
Assembly instructions – Mortar Wall Assembly instructions – Mortar Wall Download
Assembly instructions – Plasterboard Assembly instructions – Plasterboard Download
